The Jaguar Quality Policy

Through continuous improvement of our processes and systems, we will strive to provide defect-free products and effective processes that meet customer specifications and comply with ISO 9001:2015, NAP 401.1, and AS9100D requirements.

AS9100D &
ISO 9001:2015 Certified

Jaguar is registered as a Single Site quality management system in conformance with ISO 9001:2015 and AS9100D. These certifications allow us to apply our outstanding quality services to customers as we're committed to continuous improvement.

See Certification

ITAR Registered

Our facility is committed to being an ITAR-compliant company manufacturing high-quality products. We are a precision fit for projects that require quality machined components from an ITAR-registered facility.

See Registration

Quality Control

     Jaguar maintains a temperature and humidity-controlled quality lab staffed with knowledgeable inspectors fluent in advanced GD&T callouts.

    Inspection personnel meet AS9102 reporting requirements and interpret prints using ASME Y14.5 2018, 2009, and 1994 standards. They are experienced in open setup with the CMM, vision system measurements, and product verification.

Standards

  • AS9100D
  • ASME Y14.5 1994, 2009, and 2018
  • Customer specific general tolerancing and practices

Tolerances

Measured with Test Uncertainty Ratio

  • Overall: 0.0001"
  • Open set up: 0.001" (calipers, height gage, etc.)
  • CMM: 2.2μm (0.00008")
  • Keyence IM: 2.48μm (0.00009")
  • Keyence XM: 3 μm (~0.00012")

Capabilities

  • AS9102 Compliant Reporting
  • CAD creation
  • CAD alignment and measurement using the CMM and the Keyence
  • Vision System measurement
  • Calibration traceability to national standards, NIST
  • Surface finish measurement
  • Advanced GD&T knowledge

Featured Inspection Equipment

Wenzel XO-55 Coordinate Measuring Machine (CMM)

With a range of 19.685" in the X and Z direction while offering a 39.37" stroke in the Y direction. Holding an accuracy of up to 2.2 μm (~0.0000866").

Keyence
IM-7030T

The IM-7030 has a range of 8" x 12" with a holding accuracy of up to 2 μm (~ 0.000079").

Keyence
XM-2000

Also called the Handheld CMM, the XM-2000 has a measuring range of 10" x 12" x 6" with repeatability of up to 3 μm (0.000118").

Keyence
VR-6100

A 3D Optical Profilometer, the VR-6100 has a measuring range of ~ 3.6" x 3.4" x 2.7" with an accuracy of up to 2 μm (~0.000079").

Jaguar Precision Machine, LLC
